Shimamo's Steps E6002 Drive Unit features a 250 watt nominal output, walk assist mode, and Symphomaticautomatic shifting when paired with a Shimano DI2 internal gear hub. It is compatible with all brake types.
Technologies
E-Tube - Is Shimano's "service" that uses websites or apps to maximise the enjoyment of riding a bicycle by connecting the riders, the bicycles and Shimano.
Features
Easy to access -Improved feature for "quick walk assist" function
New lighting system -Brighter front and rear lighting system with a supplied 2 Amp fuse
Quick and easy assembly -Connect directly with lighting system without using SM-DUE01. Reduce firmware update time down to 12 seconds
Compatibility -Light off-road program compatible with internal geared hub system. MTB DI2 rear derailleur specification available.
Specifications
| Colour | Black/Grey |
|---|---|
| Average Weight | 3.1kg |
| Remarks | Set by E-TUBE PROJECT. ** By using SM-DUE10/SM-DUE11 |
| Compatible Brake type | V-BRAKE, Roller brake, Disc brake |
| Motor Type | Brushless motor |
| Position | Mid Ship |
| Compatible Wheel Size | *1,300 - 2,400mm |
| Continuous Rated Power | 250W |
| Maximum torque | 50Nm |
| Rated Voltage | DC 36 V |
| Power supply for front light | DC 6 V |
| Power supply for rear light | DC 6 V |
| Communication | E-Tube |
| Compatible bottom bracket type | Square Type |
| E-tube connect | 0 pcs |
| E-tube port | 2 pcs |
| Maximum current supply front and rear light total | 2A |
| Port for Speed Sensor (pcs) - SD50 type | 1 pcs |
| Port for Light | 0 pcs |
| Terminal for Light | 1 pcs |
