Still Small. Even More Useful.
Features
- 200 kg Maximum Gross Vehicle Weight
- Bosch® Cargo Line Motor provides up to 85 Nm of torque and 400% support
- Bosch dual-battery system (400 Wh) for a range of up to 195 km
- Shimano® Deore 1 × 10-speed hub for smooth, efficient shifting
- Adjustable cockpit comfortably fits riders 150 – 195 cm
- Super tough Atlas Lockstand™ auto-locks when engaged—just press a button on the handlebars to unlock
- Heavy-duty frame-integrated rear rack and integrated lower decks
- Powerful and responsive Magura® MT5 eSTOP 4-piston hydraulic disc brakes
- Always-on RearStop™ Brake Light helps you safely signal stops
- Integrated Abus® Wheel Lock, keyed-alike with the battery
- Atlas Wheels with custom CNC machined hubs for extra strength and durability
- Wide range of cargo- and passenger-carrying accessories
- Fits two Thule® Yepp Maxi seats, no adapters needed
Specifications
- General Info
- Speeds: 1 x 10
- Weight: 33.58 kg (74 lb)
- Gear Inches: 26" - 99" (2.08 - 7.91 m)
- Frame Sizes: One size
- Folding Size: 176 × 40.5 × 83 cm (69.3 × 15.9 × 32.7 in)
- Folding Time: 5 sec
- Distance:
- Seatpost to Handlebar: 49 - 59 cm (19.3 - 23.2 in)
- Saddle to Pedal: 69 - 105 cm (27.2 - 41.3 in)
- Suggested Rider Height: 150 - 195 cm (59.1 - 76.8 in)
- Max Gross Vehicle Weight: 200 kg (440.9 lb)
- Max Rider Weight: 120 kg (264.6 lb)
- Frame
- Frame: Tern GSD, 6061-AL, patented MultiTruss design, EFBE Tri-Test approved: 200 kg
- Fork: Suntour custom for Tern, 1.5" tapered Chromoly steerer, 32 mm stanchions, Thru-axle, 70 mm travel, EFBE approved: 200 kg
- Cockpit
- Handlepost: Tern Physis 3D, 3D forged, 5 patented technologies, 12°, 290 mm
- Stem: Tern Andros, adjustable, forged construction, patented technology
- Headset: Tern Flux Pro Taper, 1.5", angular contact bearings, Physis integrated
- Handlebar: Tern Sweep, 6061-AL, Tern Andros adapted
- Grips/Bar Tape: Ergon
- Saddle: Tern GSD by Velo, with rear handle
- Seatpost: Tern Telescope, 34.9/30.9 mm, 2014-AL
- Seatpost Clamp: Tern Collar, 6061-AL, 2pc
- Brakes
- Front Brake: Magura MT5, 4-piston hydraulic disc, 180 mm rotor, Sport pads
- Rear Brake: Magura MT5, 4-piston hydraulic disc, 180 mm rotor, Sport pads
- Brake Levers: Magura MT5 e-stop, hydraulic, with brake sensor
- Wheels
- Front Hub: Tern Atlas, Boost Thru-Axle, Cargo-optimized design, sealed cartridge bearing
- Rear Hub: Tern Atlas, Boost Thru-Axle, Syntace X-12 standard, Cargo-optimized design
- Spokes & Nipples: Stainless steel, 13G
- Rims: Tern Atlas, ultra wide 36 mm, dual reinforced joint
- Tires: F: Schwalbe Big Ben Plus, 55-406, Green Guard puncture protection, Reflex R: Tern x Schwalbe Super Moto-X, 62-406, Green Guard puncture protection, Reflex
- Transmission
- Shifter: Shimano Deore, 1 x 10 spd
- Rear Derailleur: Shimano Deore Shadow+
- Crankset: Tern GSD custom, forged 6061-AL DH crankarm
- Cassette/Freewheel: Shimano 11-42T, 10 spd
- Bottom Bracket: Motor integrated
- Chain: 10 spd, DHT for eBike, GST corrosion resistant coating
- Pedals: Urban with non-slip surface, sealed bearings
- Shifter Cable & Housing: Jagwire LEX-SL, slick treatment, alloy ferrules
- E-System
- Motor: Bosch Cargo Line, 400% Assist, 85 Nm Torque, max speed 25 kph (EU); max speed 20 mph (US)
- Battery: Bosch Dual Battery system, 400 Wh/900 Wh
- Display: Bosch Purion, 4 mode selectable, walk assist
- Range: 400 Wh: 42-85 km (26-53 mi); 900 Wh: 97-195 km (60-121 mi)
- Charger: 220V, 4A (EU); 100-240V, 4A (US)
- Bells & Whistles
- Bell: Pitch Plus, brass
- Chainguard: Tern Custom, full chain cover
- Kickstand: Atlas Lockstand, w/ remote unlock, patented technology
- Luggage Socket: Combo Mount
- Front Light: Tern Valo Direct, 190 lumens
- Rear Light: RearStop Brake Light, Always on brake light
- Fenders: Integrated Wheel Guard, AL6061, w/ Side Skirt
- Rack: Frame integrated, heavy duty design; Max load weight: 100 kg (220 lb)
- Accessory: ABUS, keyed-alike with Bosch battery
