We were told to win the race, be quick, efficient, keep the pace. Always chasing, seeking more, even if it makes you sore? Letting go of time, habits and doubt. Letting go of all, no rushing about. This bike's made for journeys under the sun. Together and beyond, everyone can come. Ride far and choose those endless views, until you lose.
Features
- All mounting points for your adventure: How much luggage do you want to take along on your bikepacking tour? The ATLAS answers with a resounding ‘yes’. It is approved for a system weight of 135 kg. But that's not all: the luggage and storage options of the ATLAS don't stop at mere mounting points.
- 6. Series Reinvented: The 6. series is more agile now, while still giving you a stable feel. A shorter wheelbase propels you forward and makes manoeuvring easy. More offset and less trail ensure agile, responsive handling. Added to this are less stack and the option of a longer seat post extension thanks to a shorter seat tube. This provides more flex and, therefore, more comfort.
- Tubeless-Ready System: All ATLAS models are tubeless-ready and come with 45 mm wide tyres. If you want to ride tubeless, all you have to do is remove the inner tubes, install the valves, fill with sealant, and you're ready to go. The 8.9 is delivered directly without inner tubes, with valves fitted and sealant included.
- Premium-Look: OK, this point isn't essential, but with levelled welds (putty) on the 6. series and the clean C.I.S. stem with integrated cable routing on all models, your bike simply looks chic. In addition, the paintwork on every ATLAS 8.9 is hand-painted, making each of these frames truly unique.
- Tyre Clearance: The maximum tyre clearance on the fork is 53 mm. The rear wheel can fit tyres up to 48 mm wide for the 6. series and 45 mm wide for the 8. series.
- Bye Bye Boost: We probably don't need to say much here. Road Boost is a thing of the past. All new ATLAS models come with the well-known 12x100/12x142 axle dimensions and BSA bottom bracket – for easier maintenance.
Specifications
- Frame: 6061 Aluminium, disc, 142x12 mm thru axle, flat mount 160 mm
- Fork: Carbon technologie, disc, 142x12 mm thru axle, flat mount 160 mm
- Shifter: Shimano GRX 610
- Front derailleur: Shimano GRX 820
- Rear derailleur: Shimano GRX 820, 12-speed
- Cassette: Shimano CS-HG710, 11-36T
- Chain: Shimano CN-M6100
- Crankset: Shimano GRX610, 46/30 T
- Bottom bracket: Shimano, BSA 24 mm
- Handlebar: Focus Gravel Bar, alloy, 70 mm, 114 mm, 16°
- Stem: FOCUS C.I.S. 2.0 integrated, -8°, with alloy Garmin / Wahoo-Mount
- Headset: ACROS IS52 /IS52 (ICR), FOCUS C.I.S. Integrated
- Saddle: FOCUS
- Seatpost: Carbon, 27,2 mm, set-back: 15 mm
- Brakes front | rear: Shimano GRX 610 | Shimno GRX 610
- Disc brake rotors: Shimano RT54, front: 180 mm (Size L-XL), 160 mm (Size XS-M) / rear: 160 mm
- Rim front: Rodi Blackjack SL 25, alloy, rim height: 23 mm, width: 25-622
- Rim rear: Rodi Blackjack, alloy, rim height: 23 mm, width: 25-622
- Front hub: Alexrims BRD-503
- Rear hub: Alexrims BRD-504
- Tyres front | rear: Schwalbe G-One Bite, tubeless ready, 45-622 | Schwalbe G-One Bite, tubeless ready, 45-622
- Weight: 10.3 kg (-)
- Permissible system weight: 135 kg
Please note that specifications may vary due to component availability at the time of assembly.
